Model: TH-720 / 01
- Towing
- 810 kg
- Payload
- 135 kg
- Ground Clearance
- 280–317.5 mm
Main Features
What The Numbers Buy You
Same Chassis
The 720 adds torque over the 580 without adding bulk — 55 N·m through the same proven frame.
CVTech Drive
A CVTech CVT with L / H / N / R / P and selectable 2WD/4WD with front diff lock.
Clearance By Trim
280 mm at PRO, up to 317.5 mm on higher trims — pick the ride height the terrain asks for.
ULT And MUD Available
Electronic shift, active descent control, a 1,583 kg winch and 28 in. mud tires — the top of the range is a Canadian stock trim.
Trims
Canada Takes The Top Trims
SWM builds base trims for other markets. Canada imports the top trims only.
PRO
- Triple-mode EPS
- 1,131 kg winch
- Handguards
- Mid-grade front bumper
- Rear hitch ball
- Eco / Standard / Sport modes
ULT
- Electronic gear shift
- Active descent control
- 1,583 kg winch
- Full glass tilt-up windshield
- Electric wiper and washer
- 7 in. multifunction display
- 27 in. tires, 14 in. aluminum wheels
MUD
- 28 in. mud tires, 14 in. aluminum wheels
- Mud kit
- Mud footrest
- Top-grade front and rear bumpers
- Beadlock wheels
Every Detail
Specifications
Engine
- Type
- Single-cylinder, 4-stroke, DOHC
- Displacement
- 650 cc
- Torque
- 55 N·m (42 lb-ft)
- Cooling
- Liquid-cooled
- Fuel System
- BOSCH electronic fuel injection (EFI)
- Emissions
- Meets applicable Transport Canada / EPA off-highway vehicle requirements.
Drivetrain
- Transmission
- CVTech CVT (L / H / N / R / P)
- Drive Modes
- 2WD/4WD
- Diff Lock
- Front differential lock
- Low/High Range
- High / Low range
- Final Drive
- Shaft drive
Capability
- Towing Capacity
- 810 kg
- Payload Capacity
- 135 kg (rack: 45 kg front / 90 kg rear)
- Ground Clearance
- 280–317.5 mm (by trim)
- Winch
- 1,131–1,583 kg (2,500–3,500 lb) electric winch (by trim)
Chassis
- Frame
- High-yield strength alloy steel
- Front Suspension
- Double A-arm, 240 mm travel
- Rear Suspension
- Double A-arm, 250 mm travel
- Front Brake
- Dual 200 mm discs, hydraulic twin-piston calipers
- Rear Brake
- Dual 200 mm discs, hydraulic twin-piston calipers
- Tires
- 25×8×12 / 25×10×12 (BASE) up to 28×9×14 / 28×11×14 (top trim)
- Wheels
- 12 in steel (BASE) up to 14 in aluminum (higher trims)
Dimensions
- Length
- 2,250 mm (BASE) / 2,430 mm (Touring)
- Width
- 1,200 mm
- Height
- 1,450 mm
- Wheelbase
- 1,500 mm (BASE)
- Dry Weight
- 400 kg (BASE) / up to 440 kg (Touring trims)
- Fuel Capacity
- 23 L
Electronics
- Display
- 5 in digital display (7 in multifunction on higher trims)
- EPS
- Electronic power steering (EPS)
- Lighting
- LED headlights & taillights
Additional
- Warranty
- 3-year limited factory warranty, backed by SWM Canada.
Preliminary specifications, subject to change. Compliant with applicable Transport Canada requirements.
